| TYPE | DESCRIPTION |
| Mfr | Nichicon |
| Series | UCY |
| Package | Bulk |
| Product Status | ACTIVE |
| Tolerance | ±20% |
| Package / Case | Radial, Can |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Applications | General Purpose |
| Lead Spacing | 0.295" (7.50mm) |
| Ratings | AEC-Q200 |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Capacitance | 150 µF |
| Voltage - Rated | 350 V |
| Ripple Current @ Low Frequency | 1.08 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.16 A @ 100 kHz |
